Renegade 800 X

The Renegade blends sport performance with 4x4 terrain ability.

  • Rotax 800 H.O. EFI V-Twin engine -
  • Visco-Lok 4x4 front differential with new calibration that engages front differential quicker
  • RS-Type double A-arm front suspension
  • RS-Type TTI rear suspension
  • Separate brakes levers
  • Redesigned CVT compartment for better sealing against moisture
  • ITP Holeshot ATR Radial Tires
  • Compact, digital multi-function gauge details
  • Four projector beam headlamps (60W)
  • Full floorboards with aluminum kick-up footpegs
  • Convenient 1 gal. (3.7 L) storage compartment

X package features

  • Action ShotKayaba HPG piggyback shocks with preload, high & low speed compression and rebound adjustments.
  • Rear Kayaba HPG remote-reservoir shocks with preload, high & low speed compression and rebound adjustments.
  • Black, center-cast aluminum wheels with reinforcement rings
  • Aluminum skid plate
  • Handlebar wind deflectors
  • Aluminum taper-profile handlebar with square pad
  • X package graphics
  • X package seat cover

Renegade 800 X H.O. EFI Specifications
Features

Instrumentation:

 Multi-function gauge: Speedometer, tachometer, odometer, trip & hour meters, fuel, gear position, 4x4 indicator, diagnostics, auto shut off
Electrical: Pre wired for winch
Lighting: 4 fender mounted Protector Beam headlamps (60W) with tail light/brake light
DC Outlet: Lighter type in console, standard connector in the back (15A)
X Package
Content Available:

Front KYB HPG aluminum piggyback shocks with dual speed compression, rebound and preload adjustments
Rear KYB HPG with remote reservoir shocks with dual speed compression, rebound and preload adjustments
Black, center-cast aluminum wheels with reinforcement ring
Aluminum skid plate
Handlebar wind deflectors
Aluminum taper-profile handlebar with square pad
X package graphics & seat cover
Available Colors: Black with X package graphics
Engine
Type: 799.9cc, V-twin, liquid-cooled, SOHC, 8-valve (4-valve/cyl)
Bore & Stroke 91 x 62 mm
Torque /
Net Power:		 73 Nm@ 5,500 RPM
Carburetion/EFI: 46mm Throttle Body, 2 Siemens VDO injectors
Starting System: Electric
Transmission: CVT, sub-transmission with high, low, park, neutral & reverse, standard engine braking
Drive Train: Selectable 2w/4w shaft driven with Visco-Lok† front differential
Chassis
Frame: SST

Front Suspension
Type:

RS-Type Double A-arm, forged aluminum upper arm/HPG shocks
Front Suspension
Travel:		 8.5 in (216 mm)
Rear Suspension
Type:		 RS-Type TTI independent, HPG shocks
Rear Suspension
Travel:		 9 in (229 mm)
Front Brake: 2 Hydraulic discs
Rear Break: 1 inboard hydraulic disc
Front Tires: ITP Holeshot ATRs 25 x 8 x 12 in. (ITP Holeshot ATRs 635 x 203 x 305 mm)
Back Tires: ITP Holeshot ATRs 25 x 10 x 12 in. (ITP Holeshot ATRs 635 x 254 x 305 mm)
Dimensions
L x W x H in: 86 x 46 x 45
L x W x H meter: 2.184 x 1.168 x 1.143
Wheelbase: 51 in. (1.295 m)
Dry Weight: 607 lbs. (280 kg)
Ground
Clearance: 		12 in. (305 mm)
Seat Height: 34.5 in. (877 mm)
Rack Capacity:
(Front & Rear) 		35 lbs. (16 kg), 35 lbs. (16 kg)
Towing Capacity: 1300 lbs. (590 kg)
Fuel Capacity: 5.3 US gal. (20 L)
