DS 90 X

  • Easy-to-operate 89.5 cc four-stroke engine
  • Continuously Variable Transmission (CVT) means no shifting: Forward, Neutral, Reverse
  • Long-travel Suspension
  • Cool styling reflecting the Can-Am sport quad DNA
  • Throttle limiter
  • Ergonomics specifically designed for kids.

X Package features

  • Double A-arm with HPG piggyback shocks with 7" of travel and 43" width
  • Rear HPG piggyback shock with 9" of travel and 4" width
  • Hydraulic front & rear disc brakes details
  • Tether engine-shut-off switch
  • Square race-style handlebar pad
  • Front bumper with number plate
  • Nerf bars
  • Racing kick-up pegs
  • Black aluminum rims
  • Sport-look exhaust
  • X package graphics
  • X package seat cover

Action ShotAction Shot


DS 90 X Specifications

Features

Instrumentation:

Reverse, neutral

Lighting: Day lights

X Package Content
Available:
Black aluminum rims, Double A-arm with HPG piggyback shocks with 7”of travel and 43”width, Rear HPG piggyback shock with 9”of travel and 41”width, Hydraulic front & rear disc brakes, Tether engine-shut-off switch, Square race-style handlebar pad, Front bumper with number plate, Nerf bars, Racing kick-up pegs, Sport-look exhaust, X-package graphics, Riser block, X-package seat cover.

Available Colors: Black

Engine

Type: 90cc, 4-stroke, single, force air-cooled, 2-valve

Bore & Stroke 49.5 x 48 mm

Carburetion/EFI: Carburetion, Keihin

Starting System: Electric & kick start

Transmission: Automatic CVT, forward, neutral & reverse

Drive Train: Chain driven/solid axle

Chassis

Frame: DS 90

Front Suspension
Type:

Independent A-arm

Front Suspension
Travel:
3.4 in (86 mm)

Rear Suspension
Type:
Swingarm

Rear Suspension
Travel:
6.3 in (160 mm)

Front Brake: Double drum

Rear Break: Drum

Front Tires: 19 x 7 x 8 in. (482.6 x 178 x 203 mm)

Back Tires: 18 x 9.5 x 8 in. (457 x 241 x 203 mm)

Dimensions

L x W x H in: 59.8 x 35.6 x 36.8

L x W x H meter:
1.52 x 905 x 935

Wheelbase: 39.4 in. (1 m)

Dry Weight:
245 lbs. (111 kg)

Ground
Clearance:
8.3 in. (211 mm)

Seat Height: 27 in. (685 mm)

Fuel Capacity: 1.6 US gal. (6 L)
