"We are fervent believers that this is the best pure utility ATV on the market. In fact the Traxter is the only machine we've trusted for several long wilderness expeditions. It is extremely reliable and, literally, bullet-proof." ATV Illustrated "Bombardier's new Traxter MAX will turn the ATV world upside-down. Trail riding will never be the same again." Off-Road.com Standard Features: Visco-Lok auto-locking differential Unique rear mounted radiator Exclusive step-through design Outlander 500 Specifications
Features

Instrumentation:	Speedometer, odometer, trip and hourmeter, fuel gauge

Electrical:	Pre wired for winch

Lighting:	2 fender & 1 handlebar mounted headlamps (30 W) w/ tail light/brake light

DC Outlet:	Lighter type in console, standard connector in the back (15A)

XT Package Content Available:	NA

Available Colors:	Red

Engine

Type:	498cc, 4-stroke, single, liquid-cooled, 4-valve SOHC

Bore & Stroke	100 x 63 mm

Torque / Net Power:	40 Nm @ 7,000 RPM

Carburetion/EFI:	Carburetion, Mikuni BSR 42

Starting System:	Electric w/ optional auxiliary recoil

Transmission:	CVT, sub-transmission with high, low, park, neutral & reverse

Drive Train:	4x4 shaft driven with Visco-Lok front differential

Chassis

Frame:	Traxter

Front Suspension Type:	Double A-arm

Front Suspension Travel:	7 in (178 mm)

Rear Suspension Type:	Swing Arm

Rear Suspension Travel:	7.5 in. (190.5 mm)

Front Brake:	2 hydraulic discs

Rear Break:	1 hydraulic disc

Front Tires:	25 X 8 X 12 in. (660 x 203 x 305 mm)

Back Tires:	25 x 11 x 12 in. (635 x 280 x 305 mm)

Dimensions

L x W x H in:	81.5 x 47 x 45 in.

L x W x H meter:	2,071 x 1,194 x 1,143 mm

Wheelbase:	51 in. (1,296 mm)

Dry Weight:	745 lb. (338 kg)

Ground Clearance:	9.6 in. (244 mm)

Seat Height:	37 in. (945 mm)

Rack Capacity: (Front & Rear)	90 lb. (40 kg), 175 lb. (80 kg)

Towing Capacity:	1,100 lb. (500 kg)

Fuel Capacity:	5.8 US gal. (21.8 L)
