"The DS650 Rotax engine also proved to be the fastest unit in our radar runs." ATV Sport "We like the DS650. a lot. It offers premium performance in every category and is at or very near the top of the industry in all categories - right out of the box!" ATV Illustrated Heavy duty race ready component High pressure gas shocks Alumium nerf bars Aluminum skid plates Tachometer Halogen lights Reinforced edge rims Hanguards Aluminum muffler shield DS 650 X Specifications
Features

Instrumentation:	Tachometer

Lighting:	1 dual-bulb (30 W) headlamp, 2 halogen auxiliaries (35 W) w/ tail light/brake light

Available Colors:	Black

Engine

Type:	652cc, 4-stroke, single, liquid-cooled, 4-valve DOHC

Bore & Stroke	100 x 83 mm

Carburetion/EFI:	Carburetion, Mikuni BSR 42

Starting System:	Electric

Transmission:	5-speed manual

Drive Train:	Chain driven/solid axle

Chassis

Frame:	DS

Front Suspension Type:	Double A-arm

Front Suspension Travel:	12 in (305 mm)

Rear Suspension Type:	Swing-arm

Rear Suspension Travel:	11 in (279 mm)

Front Brake:	2 hydraulic discs

Rear Break:	1 hydraulic disc

Front Tires:	22 x 7 x 10 in (559 x 178 x 254 mm)

Back Tires:	20 x 10 x 9 in (508 x 254 x 229 mm)

Dimensions

L x W x H in:	77 x 48 x 47 in

L x W x H meter:	(1,956 x 1,219 x 1,194 mm)

Wheelbase:	49 in (1,244 mm)

Dry Weight:	494 lbs (225 kg)

Ground Clearance:	11.7 in (297 mm)

Seat Height:	33.8 in (857 mm)

Fuel Capacity:	3.2 US gal (12L)
